Virgin PTFE Sheet/Rolls
Virgin PTFE sheet | Skived PTFE rollsVirgin PTFE sheets offer unmatched chemical resistance and low friction for industrial and electrical applications.
Available in multiple grades and sizes, they deliver reliable performance where durability and precision matter.
Gemini Pro‑Lon’s virgin PTFE sheets are precision-skived from high-quality resin to ensure consistent thickness and smooth, defect-free surfaces. Type 1 sheets are ideal for demanding chemical and electrical applications, while Type 2 sheets offer a cost-effective option for general-purpose use. Both grades are available in a variety of thicknesses, widths, and lengths, including slit rolls for gaskets or custom fabrication.
Virgin Skived Products
| Thickness | Size |
|---|---|
| 0.015" (1/64") | 36”X36” / 48”X48” / 48”X96” / 60”X60” |
| 0.031" (1/32") | 36”X36” / 48”X48” / 48”X96” / 60”X60” |
| 0.062" (1/16") | 36”X36” / 48”X48” / 48”X96” / 60”X60” |
| 0.093" (3/32") | 36”X36” / 48”X48” / 48”X96” / 60”X60” |
| 0.125" (1/8") | 36”X36” / 48”X48” / 48”X96” / 60”X60” |
| 0.187" (3/16") | 36”X36” / 48”X48” / 48”X96” / 60”X60” |
| 0.250" (1/4") | 36”X36” / 48”X48” / 48”X96” / 60”X60” |
| Thickness | Width | Weight |
|---|---|---|
| 0.015" (1/64") | 24” / 48" / 60” | 100-200 lbs. |
| 0.031" (1/32") | 24” / 48" / 60” | 100-200 lbs. |
| 0.062" (1/16") | 24” / 48" / 60” | 100-200 lbs. |
| 0.093" (3/32") | 24” / 48" / 60” | 100-200 lbs. |
| 0.125" (1/8") | 24” / 48" / 60” | 100-200 lbs. |
| 0.187" (3/16") | 24” / 48" / 60” | 100-200 lbs. |
| Thickness | Width | Weight |
|---|---|---|
| 0.015" (1/64") | 5" | 25 lbs. |
| 0.020" | 5" | 25 lbs. |
| 0.030" | 5" | 25 lbs. |
Whether you need standard sheets, custom sizes, or slit skived rolls, Gemini Pro‑Lon provides reliable virgin PTFE solutions tailored to your specifications. Contact us today to discuss your requirements and receive expert guidance on selecting the right material for your application.
PRODUCTS
Skived PTFE Industry Standards
| Dimensions | Weight per Sheet |
|---|---|
| 1/64"X60"X60" | 4.67 |
| 1/32"X60"X60" | 9.375 |
| 1/16"X60"X60" | 18.7 |
| 3/32"X60"X60" | 28.12 |
| 1/8"X60"X60" | 37.5 |
| 3/16"X60"X60" | 56.25 |
| 1/4"X60"X60" | 75 |
| 1/64"X48"X48" | 3 |
| 1/32"X48"X48" | 6 |
| 1/16"X48"X48" | 12 |
| 3/32"X48"X48" | 18 |
| 1/8"X48"X48" | 24 |
| 3/16"X48"X48" | 36 |
| 1/4"X48"X48" | 48 |
| 1/64"X36"X36" | 1.68 |
| 1/32"X36"X36" | 3.375 |
| 1/16"X36"X36" | 6.75 |
| 3/32"X36"X36" | 10.12 |
| 1/8"X36"X36" | 13.5 |
| 3/16"X36"X36" | 20.25 |
| 1/4"X36"X36" | 27 |
